Isuzu Diesel Fais Fab Generator Tsawg suab nrov denyo tsim 25kvA Hoobkas ncaj nqe pheej yig

Lus piav qhia luv luv:

Cov yam ntxwv tseem ceeb:
-Powered los ntawm nto moo Isuzu hom diesel cav
- Luam Denyo Design
-Compact qauv ntawm me me
-Rainproof thiab tsis tshua muaj suab nrov txo
-Kev ua haujlwm yooj yim thiab npaj siv
-Forklift qhov kom yooj yim txav
-Standard 8-10hours roj tank thiab ntau xim rau xaiv
-Widely siv nyob rau hauv kev lag luam, mining, tsev, tsheb thauj mus los.


Product Detail

Khoom Parameters

Genset Qauv Qhib hom SRT 25 Ib SRT 30 Ib SRT38I SRT45 Ib
Hom ntsiag to SRT 25 TSI SRT30 TSI SRT38 TSI SRT 45 TSI
Zaus (HZ) 50
Prime hwj chim (kva / kw) 25 / 20 30 / 24 ib 38/30.4 ib 45 / 36 ib
Standby zog (Kva / kw) 27.5/22 Nws 33/26.4 ib 42/33.5 ib 49.5 / 39.6
Cav Qauv JE493DB-02 JE493ZDB-04 JE493ZLDB-02 JE493G-15TB
Cov cim cav Dej-txias, nyob rau hauv kab, 4-stroke, ncaj qha txhaj, 1500rpm
Kev xav Ntuj Aspiration Turbocharged intercooling turbo Turbocharged, cua-cua intercooler
Lub cev muaj zog - 1500 rpm 24 kwv 28 kwv 38 kwv 43 kwv
No.of Lub tog raj kheej 4 4 4 4
Ntog x Stroke (mm) 93 * 102 hli
Kev tshem tawm (L) 2.771 ib
Compression Ratio 18.2:1 ib
Hom tswv xeev Neeg kho tshuab GAC hluav taws xob
Flywheel TSI 7.5 SAE 11.5
Flywheel Tsev SAE 4 SAE 3
Pib lub cev muaj zog 12V, 2.8kw
Roj noj @ 100% Load (L / h) 8 8 10 11
Lub Oil Capacity (L) 5.6
Coolant Peev Xwm (L) 11
Roj tank peev xwm (L) 64 64 80 88
Roj teeb loj 12v, 80 aw 12v, 80 aw 12v, 80 aw 12v, 80 aw
Alternator Qauv SRT184F SRT184G SRT 184 H SRT 224D
Cov zis (kva / kw) 27.5/22 Nws 32 / 25 ib 37.5/30 Nws 50 / 40 ib
Fais fab xwm txheej 0.8 ua
Cov cim 3Phase 4Pole, Txhuam Txhuam Txhuam Txhuam Hniav, H chav kawm rwb thaiv tsev, IP22, 12 WINDING LEADS
Qhib hom (L * W * H) mm 1800 * 750 * 1150 hli 1800 * 750 * 1150 hli 1800 * 750 * 1150 hli 1800 * 750 * 1150 hli
Qhov hnyav (Kg) 750 800 820 850
Silent hom (L * W * H) mm 2050 * 850 * 1150 hli 2050 * 850 * 1150 hli 2150 * 850 * 1150 hli 2150 * 850 * 1150 hli
Qhov hnyav (Kg) 850 900 9 20 950 ua

Khoom Qhia

Isuzu Diesel Fais Fab Generator 1
Isuzu Diesel Fais Fab Generator 2
Isuzu Diesel Fais Fab Generator 3
Isuzu Diesel Fais Fab Generator 4

Khoom Paub meej

Isuzu Diesel Fais Fab Generator 5
Isuzu Diesel Fais Fab Generator 6
Isuzu Diesel Fais Fab Generator 7
Isuzu Diesel Fais Fab Generator 8
